AnyTour E+ 3 (2024) | bike
€3,899.00
Features:
Specifications
This versatile and practical E-bike is ideal for daily commuting and other adventures. It has a full color display with on-board navigation and all the built-in features you can think of including suspension, lights, fenders and racks.
Key Performance Factors
SMART POWER
The new SyncDrive motor has Smart Assist mode, which determines the support you need and automatically adjusts power output. A carbon belt drive (on select models) delivers clean, low-maintenance performance for added reliability in rugged off-road conditions.
FULLY INTEGRATED CONTROLS
The Ride Dash Evo with on-board navigation is cleanly integrated into the stem to help riders find their way. Cables and wires for all cockpit controls, including the brakes, dropper seatpost lever, shifters, RideControl Ergo 2 and RideDash EVO, are internally routed and tucked into the frame for a tidy aesthetic.
ADVENTURES IN COMFORT
The frame’s lightweight design, available in a low-step-through or traditional double diamond style, delivers a confident, comfortable ride. Purpose-built features including an integrated trailer mount and a rear carrier rack with a MIK HD interface make it quick and easy to customize carrying capacity and add other accessories such as bags or a child seat with a secure click mechanism.
| Motor | Giant SyncDrive Core, 55Nm, Powered by Yamaha, PedalPlus 6-sensor technology |
|---|---|
| Controller | Giant RideControl Ergo 2 remote, Smart Assist automatic mode, 5 support levels, USB-C (10W) |
| Display | Giant RideDash EVO, high-angle visibility, 3″ full color LCD display, on-board navigation |
| Battery | Giant EnergyPak 625Wh, Aluminium casing with highest safety standard (EN50604), CO2 Neutral production |
| Connectivity | Giant RideControl App enabled ANT+ wireless display signal with e-bike profile |
| Sizes | S, M, L |
| Colours | Gloss Eclipse / Black |
| Frame | ALUXX SL aluminium, Integrated battery design, Headset integrated cable routing, M10 Trailer Mount, 700c Frame-set, KSA40 Kickstand |
| Fork | SR Suntour NEX E25 NLO 700C Coil 63mm,15x100mm thru-axle |
| Shock | N/A |
| Handlebar | Giant Contour GT, cable integrated, 30° back sweep, 31.8×660 mm |
| Grips | Giant Comfort Ergo Microtech Plus Lock-on |
| Stem | Giant Contour, EVO display integrated, adjustable |
| Seatpost | Suspension dropper post, 30.9mm |
| Saddle | Selle Royal Look-In gel |
| Pedals | Aluminium, Wellgo C211DU |
| Shifters | Shimano Nexus 8speed Revoshift |
| Front Derailleur | – |
| Rear Derailleur | – |
| Brakes | Shimano BR-MT200, hydraulic disc, 180mm |
| Brake Levers | Shimano BL-MT200 |
| Cassette | Gates CDC stainless steel 22T rear sprocket |
| Chain | Gates CDC Carbon Drive 120T CenterTrack belt |
| Crankset | Gates CDC CenterTrack 46T front sprocket |
| Bottom Bracket | n/a |
| Rims | Giant eX 2, Tubeless Ready, 700c Aluminium |
| Hubs | Shimano HB-TC500-15, 100x15mm thru-axle Disc [F] Shimano Nexus 8 Disc brake [R] |
| Spokes | Stainless |
| Tyres | Schwalbe Marathon E Plus 622×50, Smart DualGuard Addix E |
| Lighting | Giant Recon HL50, 50 lux [F] AXA Juno 6-12V E-bike tail light [R] |
| Lock | ABUS Xplus Battery Lock / Abus 5755L XPUS NR |
| Carrier | MIK rack. System bag & basket compatible |
Geometry
| S | M | L | ||
|---|---|---|---|---|
| A | SEAT TUBE LENGTH | 410 | 460 | 480 |
| B | SEAT TUBE ANGLE | 72.5 | 72.5 | 72 |
| C | TOP TUBE LENGTH | 590 | 590 | 610 |
| D | HEAD TUBE LENGTH | 130 | 130 | 170 |
| E | HEAD TUBE ANGLE | 69.5 | 69.5 | 69.5 |
| F | FORK RAKE | 44 | 44 | 44 |
| G | TRAIL | 90.6 | 91 | 91 |
| H | WHEEL BASE | 1114 | 1114 | 1130 |
| I | CHAIN STAY LENGTH | 470 | 470 | 470 |
| J | BOTTOM BRACKET DROP | 70 | 70 | 70 |
| K | STACK | 663 | 663 | 663 |
| L | REACH | 392 | 392 | 394 |
| M | STAND OVER HEIGHT | 588 | 588 | 540 |
| N | HANDLERBAR WIDTH | 660 | 660 | 660 |
| O | STEM LENGTH | 90 | 90 | 110 |
| P | CRANK LENGTH DEC | 170 | 170 | 170 |
| Q | WHEEL SIZE ALT | 700C | 700C | 700C |
