Sizes |
EEL,EEM,EES,EEXS,L,M,S,TM,TS,XL |
Colours |
red/black |
Frame |
Aluminium Superlite, Gravity Casting Technology, Efficient Comfort Geometry, Boost148, Fully Integrated Battery, Integrated Carrier 3.0, Advanced Internal Cable Routing, 1.5 Headtube (EE: Tapered Headtube) |
Fork |
SR Suntour XCR32 LO-R Air, Tapered, 15x110mm, 100mm, Lockout |
Shock |
N/A |
Handlebar |
CUBE Comfort Trail Bar, 700mm |
Grips |
ACID Travel Comfort |
Stem |
CUBE Comfort Stem Pro, 31.8mm, Adjustable |
Seatpost |
CUBE Suspension Seatpost HD, 30.9mm |
Saddle |
Natural Fit Sequence Comfort |
Pedals |
ACID PP Trekking |
Shifters |
Shimano Deore SL-M6100-IR, Direct Attach |
Front Derailleur |
N/A |
Rear Derailleur |
Shimano Deore RD-M6100-SGS, ShadowPlus, 12-Speed |
Brakes |
Shimano BR-MT420/MT410, Hydr. Disc Brake (180/180) |
Brake Levers |
N/A |
Cassette |
Shimano Deore CS-M6100, 10-51T |
Chain |
Shimano CN-M6100 |
Crankset |
ACID E-Crank, 40T, 175mm (EE: 170mm) |
Bottom Bracket |
N/A |
Rims |
CUBE EX23, 36H, Disc, Tubeless Ready |
Hubs |
Shimano HB-MT400-B, 15mm, Boost, Centerlock |
Tyres |
Schwalbe Energizer Plus, Performance, Green Guard, 55-622 |
Shock hardware |
N/A |
Headset |
M/Z: ACROS AZF-1035, ICR (Integrated Cable Routing), BlockLock 120°, Top Zero-Stack 1 1/2″ (ZS 56mm), Bottom Zero-Stack 1 1/2″ (ZS 56mm) // EE: ACROS AZX-1040, BlockLock 135°, Top Zero-Stack 1 1/8″ (ZS 44mm), Bottom Zero-Stack 1 1/2″ (ZS 56mm) |
Bar extensions |
N/A |
Handlebar tape |
N/A |
Number of gears |
12 |
Rear hub |
Shimano FH-MT410-B, 12mm, Boost, Centerlock |
Seat post clamp |
CUBE Screwlock Semi Integrated w/ Hidden Tool, 36mm (EE: CUBE Screwlock Semi Integrated, 36mm) |
Front light |
CUBE Shiny 50 Lux, 12V, DC |
Rear light |
CUBE Shiny 50 Lux, 12V, DC |
Kickstand |
ACID FM Pure Kickstand |
Mudguard |
ACID 65 Integrated Carrier 3.0 |
Chain protection |
N/A |
Bell |
Ring Bell |
Carrier |
ACID Integrated Carrier 3.0, CUBE Adapter Compatible |
Engine |
Bosch Drive Unit Performance CX Generation 4 (85Nm) Cruise (250Watt), Smart System |
Battery |
Bosch PowerTube 750 |
Charger |
Bosch 4A |
Display |
Bosch Kiox 300 |
Integratedbar/stem |
N/A |
Chain guide |
N/A |
Integrated shifters/brakelevers |
N/A |
Brake system |
Shimano BR-MT420/MT410, Hydr. Disc Brake (180/180) |
Crankset chainring sizes |
40T |
Gear Teeth |
N/A |
Wheelset (system wheels) |
N/A |
Front tire |
N/A |
Rear tire |
N/A |
Net weight (kg) |
27.7 |
