Sizes |
S,M,L,XL,TXS,TS,TM,EEXS,EES,EEM,EEL |
Colours |
grey/white |
Frame |
Aluminium Superlite, Gravity Casting Technology, Efficient Comfort Geometry, Full Integrated Battery, 1.5 Headtube, Semi Integrated Carrier |
Fork |
SR Suntour NVX30 Coil, 63mm |
Headset |
ACROS AZF-1031, Top Zero-Stack 1 1/2″ (ZS 56mm), Bottom Zero-Stack 1 1/2″ (ZS 56mm) |
Stem |
CUBE Performance Stem Pro, 31.8mm |
Handlebar |
CUBE Comfort Trail Bar, 700mm |
Grips |
ACID Travel Comfort |
Rear Derailleur |
Shimano RD-M3100-SGS, 9-Speed |
Shifters |
Shimano SL-M3100-R, Rapidfire-Plus |
Brakes system |
Shimano BR-MT200, Hydr. Disc Brake (180/180) |
Crankset |
ACID E-Crank, 40T, 170mm |
Crankset chainring sizes |
40T |
Cassette |
Shimano CS-HG201, 11-36T |
Number of gears |
9 |
Chain |
KMC X9 |
Rims |
Rodi Blackrock 23, 36H, Disc, Tubeless Ready |
Front hub |
Shimano HB-TX505, QR, Centerlock |
Rear hub |
Shimano FH-TX505, QR, Centerlock |
Tyres |
Schwalbe Big Ben, Active, K-Guard, 55-622 |
Pedals |
ACID PP Trekking |
Saddle |
Natural Fit Sequence Comfort |
Seatpost |
CUBE Performance Post, 30.9mm |
Seat post = dropper Yes/No |
N |
Seat post clamp |
CUBE Screwlock Semi Integrated w/ Hidden Tool, 36mm |
Front light |
CUBE Shiny 50 Lux, 12V, DC |
Rear light |
ACID Mudguard Rear Light PRO-E, 12V, DC |
Kickstand |
ACID FM Pure Kickstand |
Mudguard |
ACID 65 BB-Mount |
Bell |
Easy Bell |
Carrier |
ACID Semi-Integrated Carrier, ACID RILink Adapter Compatible |
Engine |
Bosch Drive Unit Performance Generation 3 (75Nm) Cruise (250Watt), Smart System |
Battery |
Bosch PowerTube 500 |
Charger |
Bosch 4A |
Display |
NA |
Gross weight |
31.5 |
Net weight |
26.5 |
