Fathom E+ 2 (2024) | bike
€3,799.00
Features:
Specifications
Take control of the trail with this fun new hardtail E-bike. Now you can climb with greater ease and ride farther—the perfect formula for a great day on the trail.
Key Performance Factors
Smooth power delivery
The new SyncDrive Sport motor delivers smooth, instantaneous power with 75Nm of torque to help riders climb steep hills and extend their trail riding capabilities.
Balanced, confident handling
Lightweight aluminum frame with trail-friendly geometry, 130mm of front suspension travel, and stable 29-inch wheels with tubeless tires puts you in control even in the toughest off-road terrain.
Long-lasting battery
Integrated EnergyPak Smart with 625Wh of capacity is easy to charge up to 80 percent in 2.5 hours with our 4A Fast Charger.
| Motor | Giant SyncDrive Sport2, 75Nm, PedalPlus 6-sensor technology |
|---|---|
| Controller | Giant RideControl Dash, Smart Assist automatic mode, 5 support levels, USB-C (10W) |
| Display | Giant RideControl Dash, high-angle visibility, full color LCD display |
| Battery | Giant EnergyPak 625Wh, Aluminium casing with highest safety standard (EN50604), CO2 Neutral production, Giant EnergyPak Plus 250 range extender compatible |
| Charger | Giant EnergyPak 4A smart charger compact, 60% charge in 2:30h |
| Connectivity | Giant RideControl App enabled ANT+ wireless display signal with e-bike profile |
| Sizes | S, M, L, XL, XXL |
| Colours | Gloss Gunmetal Black |
| Frame | ALUXX SL aluminium, Overdrive 1.5″ – 1.8″ head tube, 148x12mm thru-axle, integrated KSA40 kickstand mount, EnergyPak Plus range extender compatible |
| Fork | SR Suntour XCR 34 Boost 2-CR Coil 29, 130mm travel, Tapered 1.125″-1.5″ steerer, 15AH2-110 thru-axle |
| Handlebar | Giant Connect TR Riser 31.8mm |
| Grips | Giant Tactal Pro, single lock-on |
| Stem | Giant Contact |
| Seatpost | Giant Contact Switch Adj, adjustable dropper, 30,9mm |
| Saddle | Giant Ergo Contact Trail |
| Pedals | Aluminium Platform |
| Shifters | Shimano Cues LinkGlide 1×9 |
| Rear Derailleur | Shimano Cues LinkGlide |
| Brakes | Tektro HD-M285, hydraulic disc, 180mm [F/R] |
| Brake Levers | Tektro HD-M285 |
| Cassette | Shimano Cues, LinkGlide, CS-LG300-9, 11-46T, 9-speed |
| Chain | KMC eGlide NP/BK, e-bike optimised |
| Crankset | FSA MegaTooth direct-mount 1X steel 36T FSA Comet E-Bike crank arm |
| Rims | Giant XCT 29 Tubeless Ready 25mm e-bike optimised |
| Hubs | Giant eTracker Boost 15×110 [F] 12×148 [R] |
| Spokes | Stainless steel |
| Tyres | Maxxis Rekon 29×2.4″ Wire Bead 60TPI |
| Lighting | – |
| Carrier | – |
Geometry
| S | M | L | XL | XXL | ||
|---|---|---|---|---|---|---|
| A | SEAT TUBE LENGTH | 380 | 420 | 460 | 495 | 530 |
| B | SEAT TUBE ANGLE | 75 | 75 | 75 | 75 | 75 |
| C | TOP TUBE LENGTH | 590 | 610 | 630 | 650 | 670 |
| D | HEAD TUBE LENGTH | 110 | 120 | 130 | 140 | 150 |
| E | HEAD TUBE ANGLE | 66 | 66 | 66 | 66 | 66 |
| F | FORK RAKE | 51 | 51 | 51 | 51 | 51 |
| G | TRAIL | 113.4 | 113.4 | 113.4 | 113.4 | 113.4 |
| H | WHEEL BASE | 1197 | 1219 | 1241 | 1262 | 1284 |
| I | CHAIN STAY LENGTH | 470 | 470 | 470 | 470 | 470 |
| J | BOTTOM BRACKET DROP | 65 | 65 | 65 | 65 | 65 |
| K | STACK | 647 | 656 | 665 | 675 | 684 |
| L | REACH | 416 | 434 | 451 | 469 | 486 |
| M | STAND OVER HEIGHT | 730 | 757 | 750 | 773 | 776 |
| N | HANDLERBAR WIDTH | 750 | 780 | 780 | 780 | 780 |
| O | STEM LENGTH | 40 | 40 | 50 | 50 | 50 |
| P | CRANK LENGTH DEC | 165 | 165 | 165 | 165 | 165 |
| Q | WHEEL SIZE ALT | [F] 29″ [R | [F] 29″ [R | [F] 29″ [R | [F] 29″ [R | [F] 29″ [R |
