Langma Advanced SL Disc 0 (2024) | Women bike
€12,599.00
Features:
Specifications
Already favored by climbing addicts and WorldTour racers, the all-new Langma Advanced SL Disc is redesigned to be lighter, stiffer, and ready to throw down on race day.
Key Performance Factors
Featherweight efficiency
The heart of the Langma is an ultra-light Advanced SL-grade composite frameset—which we’ve rebuilt with longer, more continuous pieces of carbon fiber for a stiffer bike that’s 60 grams lighter.* So you get a responsive ride that accelerates immediately,
Intuitive handling
We’ve re-engineered the Langma fork for 50% more lateral stiffness,* for precise handling and responsiveness. An oversized headset and all-new Liv Contact SLR handlebar boost control without sacrificing aerodynamics. Integrated, flat-mount disc brakes del
Aero advantage
Updated truncated ellipse tubing reduces wind drag at a wider range of yaw angles, gaining you precious seconds in flats, descents, and headwinds. Our relentless testing and refinement have also inspired the development of the new fully-carbon Variant SLR
| Sizes | XS, S, M |
|---|---|
| Colours | Gloss Raw Carbon/Chrome |
| Frame | Advanced SL-grade composite, 12x142mm thru-axle, disc |
| Fork | Advanced SL-grade composite, full-composite OverDrive 2 steerer, 12x100mm, disc |
| Shock | N/A |
| Handlebar | Liv Contact SLR XS: 360mm, S: 380mm, M: 400mm |
| Grips | Liv All Condition |
| Stem | Giant Contact SLR XS: 80mm, S: 90mm, M: 100mm |
| Seatpost | Giant Variant SLR, composite |
| Saddle | Liv Alacra SLR |
| Pedals | PEDALS NOT SUPPLIED |
| Shifters | Shimano Dura-Ace Di2 ST-R9270 2×12 |
| Front Derailleur | Shimano Dura-Ace Di2 ST-R9250 |
| Rear Derailleur | Shimano Dura-Ace Di2 ST-R9250 |
| Brakes | Shimano Dura-Ace Di2 hydraulic, Shimano RT-MT900 rotors [F]160mm, [R]140mm |
| Brake Levers | Shimano Dura-Ace Di2 |
| Cassette | Shimano Dura-Ace, 12-speed, 11×34 |
| Chain | Shimano Dura-Ace M9100 |
| Crankset | Shimano Dura-Ace, 36/52 with Shimano FC-9200P power meter XS: 165mm, S: 170mm, M: 170mm |
| Bottom Bracket | Shimano, press fit |
| Rims | CADEX 36 Disc WheelSystem, [F] 36mm, [R] 36mm |
| Hubs | [F] CADEX Low Friction Hub, CenterLock, 12mm thru-axle, [R] CADEX R1-C30 Hub, CenterLock, 12mm thru-axle |
| Spokes | CADEX Aero Carbon |
| Tyres | CADEX Race, tubeless, 700x25c (28mm), folding |
| Extras | computer mount, tubeless prepared, 32mm max tyre size |
Geometry
| XS | S | M | ||
|---|---|---|---|---|
| A | SEAT TUBE LENGTH | 420 | 450 | 480 |
| B | SEAT TUBE ANGLE | 75 | 74.5 | 74 |
| C | TOP TUBE LENGTH | 508 | 524 | 540 |
| D | HEAD TUBE LENGTH | 120 | 135 | 155 |
| E | HEAD TUBE ANGLE | 71 | 72 | 72.5 |
| F | FORK RAKE | 49 | 49 | 49 |
| G | TRAIL | 67.8 | 61.4 | 58.2 |
| H | WHEEL BASE | 973 | 977 | 984 |
| I | CHAIN STAY LENGTH | 405 | 405 | 405 |
| J | BOTTOM BRACKET DROP | 72 | 70 | 70 |
| K | STACK | 517 | 532 | 553 |
| L | REACH | 370 | 377 | 382 |
| M | STAND OVER HEIGHT | 700 | 730 | 760 |
| N | HANDLERBAR WIDTH | 360 | 380 | 400 |
| O | STEM LENGTH | 80 | 90 | 100 |
| P | CRANK LENGTH DEC | 165 | 170 | 170 |
| Q | WHEEL SIZE ALT | 700C | 700C | 700C |
