Revolt Advanced Pro 0 (2024) | bike
€6,299.00
Features:
Specifications
Fast gravel is fun gravel. The bike of choice for Giant gravel racing pros, this superlight speedster delivers a smooth ride over rugged roads, and is adaptable to all types of conditions and riding styles.
Key Performance Factors
Lightweight efficiency
Advanced composite frame and Advanced SL composite fork save a combined 200g compared to previous generation. Updated geometry includes a lower bottom bracket, longer reach, and steeper head tube angle for improved acceleration and climbing.
Tuned compliance
A lowered seatstay junction with smaller diameter tubes absorbs road shocks and vibrations. The Contact SLR D-Fuse carbon handlebar and D-Fuse seatpost work as a system to optimize compliance without sacrificing stiffness while cornering, sprinting and cl
Adaptable to the terrain
A flip chip on the rear dropout adjusts the wheelbase short for quicker handling, or long for improved stability at speed. The long setting also allows for larger diameter tires up to 53mm. You can choose the included D-Fuse seatpost for maximum complianc
| Sizes | S, M, M/L, L, XL |
|---|---|
| Colours | Gloss Digital Blurple/Iris |
| Frame | Advanced-grade composite, 12x142mm thru-axle, disc, flip chip dropout |
| Fork | Advanced SL-grade composite, full-composite OverDrive steerer, 12mm thru-axle, disc |
| Shock | N/A |
| Handlebar | Giant Contact SLR XR D-Fuse, 31.8mm S:42cm, M:44cm, M/L:44cm, L:46cm, XL:46cm |
| Grips | Stratus Lite 3.0 |
| Stem | Giant Contact, 8-degree S:60mm, M:70mm, M/L:80mm, L:80mm, XL:90mm |
| Seatpost | Giant D-Fuse SL, composite, -5/+15mm offset |
| Saddle | Giant Approach SL |
| Pedals | PEDALS NOT SUPPLIED |
| Shifters | SRAM Force eTap AXS, 2×12 |
| Front Derailleur | SRAM Force eTap AXS |
| Rear Derailleur | SRAM Force eTap AXS |
| Brakes | SRAM Force eTap AXS hydraulic, SRAM CenterLine rotors [F]160mm, [R]160mm |
| Brake Levers | SRAM Force eTap AXS hydraulic |
| Cassette | SRAM Force, 12-speed, 10×36 |
| Chain | SRAM Force D1 |
| Crankset | SRAM Force D1 DUB, 30/43 S:170mm, M:172.5mm, M/L:172.5mm, L:175mm, XL:175mm |
| Bottom Bracket | SRAM DUB, press fit |
| Rims | Giant CXR 1 Carbon Disc WheelSystem, [F] 35mm, [R] 35mm |
| Hubs | [F] Giant AR alloy, CenterLock, 12mm thru-axle, [R] Giant AR alloy, DT350 36t ratchet driver, CenterLock, 12mm thru-axle |
| Spokes | Sapim CX-Ray |
| Tyres | CADEX AR, 700x40c, tubeless |
| Extras | Factory tubeless set up, 53mm max tyre size in “long” flip chip position, 45mm max tyre size in “short” flip chip position |
| Max Chainring Size | SRAM Wide 2x 43-30, 1x 46T. Shimano GRX 2x 48-31, 1x 42T |
Geometry
| M | ML | S | XL | L | ||
|---|---|---|---|---|---|---|
| A | SEAT TUBE LENGTH | 470 | 490 | 450 | 530 | 510 |
| B | SEAT TUBE ANGLE | 73.5 | 73 | 73.5 | 73 | 73 |
| C | TOP TUBE LENGTH | 560 | 575 | 550 | 600 | 585 |
| D | HEAD TUBE LENGTH | 150 | 165 | 135 | 195 | 180 |
| E | HEAD TUBE ANGLE | 71.5 | 72 | 71 | 72 | 72 |
| F | FORK RAKE | 50 | 50 | 50 | 50 | 50 |
| G | TRAIL | 68 | 65 | 72 | 65 | 65 |
| H | WHEEL BASE | 1026 | 1031 | 1020 | 1056 | 1041 |
| I | CHAIN STAY LENGTH | 425 | 425 | 425 | 425 | 425 |
| J | BOTTOM BRACKET DROP | 80 | 80 | 80 | 80 | 80 |
| K | STACK | 586 | 602 | 570 | 630 | 616 |
| L | REACH | 387 | 391 | 381 | 407 | 397 |
| M | STAND OVER HEIGHT | 757 | 774 | 740 | 807 | 791 |
| N | HANDLERBAR WIDTH | 440 | 440 | 420 | 460 | 460 |
| O | STEM LENGTH | 70 | 80 | 60 | 90 | 80 |
| P | CRANK LENGTH DEC | 172.5 | 172.5 | 170 | 175 | 175 |
| Q | WHEEL SIZE ALT | 700C | 700C | 700C | 700C | 700C |
