Trance X Advanced 1 (2024) | bike
€6,899.00
Features:
Specifications
Float up technical climbs and sail down chunky descents. This all-new, full-composite trail bike gives you 140mm of smooth Maestro rear suspension and all sorts of adjustability. You can dial in frame geometry and switch the rear wheel size for the terrain.
Key Performance Factors
More Travel
New Maestro rear suspension adds 5mm of travel over previous generation, going from 135mm to 140mm. A trunnion mount shock and Advanced Forged Composite rocker arm combine for a longer stroke with a smooth, active feel. Rear suspension is paired with a 150mm travel fork for superior confidence and control on technical singletrack terrain.
Adjustable trail geometry
A three-position Maestro flip chip lets you dial in frame geometry for your riding style and terrain. The high setting adds more ground clearance, a good option for tight, technical terrain. The low setting creates a slacker head angle and lower bottom bracket for confident handling at higher speeds. The middle position is neutral. In addition, a new headset flip chip provides 10mm of reach adjustment.
Rear wheel options
All models come with 29-inch front and rear wheels, but the flip chip lets you opt for a mixed wheel setup including a 27.5 rear. The stock setup optimizes stability and roll-over speed, while a 27.5 rear wheel delivers a snappier feel and more saddle-to-tire clearance. Some riders favor this “mullet” setup for riding steep, technical terrain.
| Sizes | S, M, L, XL |
|---|---|
| Colours | Gloss Arctic Light/Chrome |
| Frame | Advanced-grade composite front and rear triangles, 140mm Maestro suspension, flip chip – Maestro 3, flip chip – headset, 12x148mm thru-axle |
| Fork | Fox 36 Performance Elite, GRIP2 damper, 44mm offset, 150mm, 15×110 Kabolt X, custom tuned for Giant |
| Shock | Fox Float X Performance Elite, 185/52.5, custom tuned for Giant |
| Handlebar | Giant Contact SLR TR35, 780x35mm, 20mm rise |
| Grips | Giant Tactal Pro Single S:120mm, M:120mm, L:130mm, XL:130mm |
| Stem | Giant Contact SL 35 S:40mm, M:40mm, L:50mm, XL:50mm |
| Seatpost | Giant Contact Switch Adjustable, remote S: 110-140mm travel / 30.9 x 395mm M: 140-170mm travel / 30.9 x 470mm L: 170-200mm travel / 30.9 x 530mm XL: 170-200mm travel / 30.9 x 530mm |
| Saddle | Giant Romero SL |
| Pedals | PEDALS NOT SUPPLIED |
| Shifters | SRAM AXS, 1×12 |
| Front Derailleur | N/A |
| Rear Derailleur | SRAM GX Eagle Transmission AXS |
| Brakes | Shimano Deore XT BR-MT8120, hydraulic, Shimano RT-66 rotors [F]203mm, [R]180mm |
| Brake Levers | Shimano Deore XT BL-M8100 |
| Cassette | SRAM GX-1275, 10×52 |
| Chain | SRAM GX Eagle |
| Crankset | SRAM GX, 30t, 55mm chainline |
| Bottom Bracket | SRAM DUB, Press Fit |
| Rims | Giant TRX, 29″ hookless carbon wheelsystem, 30mm IW, 40mm OW, 22mm H, 72t POE, 28 SP spokes, DBL technology, XD driver body |
| Hubs | [F] Giant Alloy, 6 Bolt [R] TRX HE, Alloy, 72 Pawl Driver, 6 bolt |
| Spokes | Sapim, 28, straight pull, DBL Technology |
| Tyres | [F] Maxxis Minion DHF, 29×2.5 WT, 3C 60 tpi, MaxxTerra, EXO, TR [R] Maxxis Dissector 29×2.4 WT, 60 tpi, 3C MaxxTerra, TR, tubeless |
| Extras | Factory tubeless set up, 2.5″ max tyre size, 34t max chainring size, 3M tailgate protector |
Geometry
| S | M | L | XL | ||
|---|---|---|---|---|---|
| A | SEAT TUBE LENGTH | 400 | 425 | 450 | 475 |
| B | SEAT TUBE ANGLE | 76.8 | 76.8 | 76.8 | 76.8 |
| C | TOP TUBE LENGTH | 571 | 602 | 624 | 657 |
| D | HEAD TUBE LENGTH | 100 | 105 | 115 | 125 |
| E | HEAD TUBE ANGLE | 64.4 | 64.4 | 64.4 | 64.4 |
| F | FORK RAKE | 44 | 44 | 44 | 44 |
| G | TRAIL | 134.1 | 134 | 133.9 | 133.9 |
| H | WHEEL BASE | 1190 | 1222 | 1246 | 1281 |
| I | CHAIN STAY LENGTH | 440 | 440 | 440 | 440 |
| J | BOTTOM BRACKET DROP | 40 | 40 | 40 | 40 |
| K | STACK | 617 | 621 | 631 | 640 |
| L | REACH | 426 | 456 | 476 | 507 |
| M | STAND OVER HEIGHT | 733 | 737 | 754 | 752 |
| N | HANDLERBAR WIDTH | 800 | 800 | 800 | 800 |
| O | STEM LENGTH | 40 | 40 | 50 | 50 |
| P | CRANK LENGTH DEC | 165 | 170 | 170 | 170 |
| Q | WHEEL SIZE ALT | [F] 29″ [R | [F] 29″ [R | [F] 29″ [R | [F] 29″ [R |
