Trance X SX (2024) | bike
€3,799.00
Features:
Specifications
From loam to chunder, alpine peaks to desert rock, this trail slayer has a 29-inch front wheel and 27.5-inch rear for the ultimate combo of quickness and control. With 145mm of rear suspension, a beefy 160mm fork, and adjustable geometry, it’s ready to let loose on black diamond descents.
Key Performance Factors
Updated suspension
This “SX” series features all-new Maestro rear suspension with added travel (145mm) for technical singletrack and rugged descents. The trunnion mount shock and Advanced Forged Composite rocker arm combine for a longer stroke that has a smooth, active feel, plus greater stiffness in the chassis for precision control. The rear suspension is paired with a longer travel 160mm fork, giving riders superior confidence and control on the descents.
Adjustable trail geometry
A three-position Maestro flip chip lets riders dial in frame geometry to suit their riding style and terrain. The high setting adds more ground clearance, a good option for tight, technical terrain. In the low setting, the head tube gets slacker and the bottom bracket drops, ideal for confident handling at higher speeds. The middle position is neutral. In addition, a new headset flip chip adjusts reach so you can easily achieve your preferred positioning.
Mixed wheel setup
A 29-inch front wheel provides speed, stability and front-end control on rough, technical trails. A 27.5-inch rear wheel adds agility and maneuverability to help riders rail corners, pop over features and show off their style.
| Sizes | S, M, L, XL |
|---|---|
| Colours | Gloss Golden Haze |
| Frame | ALUXX SL-grade aluminium front and rear triangles, 145mm Maestro suspension, flip chip – Maestro 3, flip chip – headset, 12x148mm thru-axle |
| Fork | Fox 36 Float Rhythm, GRIP damper, 44mm offset, 160mm, 15×110 Kabolt, custom tuned for Giant |
| Shock | Marzocchi Bomber Air, 185/55, custom tuned for Giant |
| Handlebar | Giant Contact TR35, 780x35mm, 20mm rise |
| Grips | Giant Tactal Pro Single S:120mm, M:120mm, L:130mm |
| Stem | Giant Contact SL 35 S:40mm, M:40mm, L:50mm |
| Seatpost | Giant Contact Switch Adjustable, remote S: 110-140mm travel / 30.9 x 395mm M: 140-170mm travel / 30.9 x 470mm L: 170-200mm travel / 30.9 x 530mm |
| Saddle | Giant Romero |
| Pedals | PEDALS NOT SUPPLIED |
| Shifters | Shimano Deore, 1×12 |
| Front Derailleur | N/A |
| Rear Derailleur | Shimano Deore |
| Brakes | Shimano Deore BR-MT420, hydraulic, Shimano RT-66 rotors [F]203mm, [R]180mm |
| Brake Levers | Shimano Deore BL-MT401 |
| Cassette | Shimano Deore, 10×51 |
| Chain | KMC X-12 |
| Crankset | Praxis Cadet, 30t, 55mm chainline |
| Bottom Bracket | Praxis, press fit |
| Rims | Giant TRA 2, 29″ wheelset, hookless aluxx wheelsystem, 30mm inner width, 40mm outer width |
| Hubs | [F] Giant MTB alloy, six-bolt [R] Giant MTB alloy, 72t POE (Points of Engagement), six-bolt, MicroSpline driver body |
| Spokes | Sapim, 28, J-bend |
| Tyres | [F] Maxxis Minion DHF, 29×2.5 WT, 60 tpi, EXO, TR [R] Maxxis Dissector 27.5×2.4 WT, 60 tpi, EXO TR, tubeless |
| Extras | Factory tubeless set up, 2.5″ max tyre size, 36t max chainring size |
Geometry
| S | M | L | ||
|---|---|---|---|---|
| A | SEAT TUBE LENGTH | 400 | 425 | 450 |
| B | SEAT TUBE ANGLE | 75.5 | 75.6 | 75.6 |
| C | TOP TUBE LENGTH | 574 | 605 | 627 |
| D | HEAD TUBE LENGTH | 100 | 105 | 115 |
| E | HEAD TUBE ANGLE | 63.1 | 63.2 | 63.2 |
| F | FORK RAKE | 44 | 44 | 44 |
| G | TRAIL | 143.9 | 143.6 | 143.3 |
| H | WHEEL BASE | 1194 | 1226 | 1250 |
| I | CHAIN STAY LENGTH | 440 | 440 | 440 |
| J | BOTTOM BRACKET DROP | 30 | 31 | 30 |
| K | STACK | 626 | 631 | 640 |
| L | REACH | 413 | 443 | 463 |
| M | STAND OVER HEIGHT | 725 | 739 | 762 |
| N | HANDLERBAR WIDTH | |||
| O | STEM LENGTH | 40 | 40 | 50 |
| P | CRANK LENGTH DEC | 165 | 170 | 170 |
| Q | WHEEL SIZE ALT | [F] 29″ [R | [F] 29″ [R | [F] 29″ [R |
